The SR200B is a popular machine as the medium sized frame looks and feels compact but offers operators the performance of a larger machine. This is also thanks to the punchy and responsive 3.2 litre, FPT engine delivering power on demand. The new cab interior layout ensures operator a comfortable and safety operator workspace. The single piece frame design and our long wheelbase, we maximize stability and lift capacity. With an easy forward tilting cab access to all major components makes servicing a breeze.Â
Comprehensive planned maintenance solutions designed to enhance uptime, extend equipment life, and ensure peak performance on every job.
Advanced protection plans offering extensive coverage to safeguard your equipment, reduce downtime, and ensure peace of mind.
A powerful telematics system providing real-time insights into equipment performance, efficiency, and location to maximize productivity.
Seamless remote diagnostics and support tools enable quick issue resolution, minimize delays, and keep your machines operational.
| Models | SR200B |
|---|---|
|
Over all height with bucket* mm |
4198 |
|
Maximum hinge pin height mm |
3178 |
|
Top of ROPS mm |
2002 |
|
Bottom of bucket fully raised height* mm |
2998 |
|
Length with out attachment mm |
2981 |
|
Length with bucket* mm |
3843 |
|
Dump angle |
38 |
|
Maximum dump height* mm |
2419 @ 38 |
|
Maximum reach mm |
677 |
|
Roll back angle at ground level ° |
30 |
|
Roll back angle at maximum height ° |
99 |
|
Wheelbase mm |
1322 |
|
Ground clearance mm |
203 |
|
Angle of departure ° |
23 |
|
Rear axle to bumper mm |
1034 |
|
Over all width (Spec tire) mm |
1768 |
| Models | SR200B |
|---|---|
|
Boom geometry |
Radial |
|
Rated operating capacity 50% (ROC) kg |
1000 |
|
Tipping load kg |
2000 |
|
Lift cylinder breakout force kN |
24,4 |
|
Bucket breakout force kN |
38,7 |
| Models | SR200B |
|---|---|
|
Engine manufacturer |
FPT |
|
Engine model |
F5C E5454 B |
|
Displacement l |
3,2 |
|
Rated gross power output (SAE J1349) kW/hp |
61/82 @ 2500 rpm |
|
Peak Torque Nm |
305 @ 1400 rpm |
| Models | SR200B |
|---|---|
|
Low Range Km/h |
11,3 |
|
High Range Km/h |
16,9 |
| Models | SR200B |
|---|---|
|
Pump flow rate STD l/min |
85 |
|
Operating pressure STD bar |
210 |
|
High flow option* l/min |
142 |
|
High flow pressure option* bar |
210 |
| Models | SR200 B |
|---|---|
|
Operating weight Kg |
3350 |
|
Shipping weight Kg |
3200 |
